ACTI9 COMB BUSBAR AUX2P 100A 57MODULES
| Pilih Arus pengenal |
|
||||||||||||||||||||||||||||||
| Pilih Jumlah kutub |
|
||||||||||||||||||||||||||||||
| Kode Produk | A9XAH257 | ||||||||||||||||||||||||||||||
| Nama Produk | ACTI9 COMB BUSBAR AUX2P 100A 57MODULES | ||||||||||||||||||||||||||||||
| Keterangan | COMB BUSBAR 18MM PITCH SCHNEIDER ELECTRIC - A9XAH257 | ||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||
| Rated Current | 100A | ||||||||||||||||||||||||||||||
| Tipe | Linergy | ||||||||||||||||||||||||||||||
|
Download the A9XAH257 Acti 9 comb busbar 1L+N wih Aux 18 mm pitch 57 modules 100A product datasheet, by clicking here! Comb Busbar Schneider Electric Comb Busbar is one of the most basic switchgear instruments that distributes electricity to MCS or ELCB switchgear components. The use of comb busbar can create a more organized and cleaner cable system on the distribution board. Comb Busbar Function :
Technical Characteristic :
You can shop safely at ListrikKita.com because all the items we sell are guaranteed 100% original, officially guaranteed, and can be accompanied by a letter of authenticity of the goods. For more information or to make a large purchase, please contact our sales or marketing team by clicking here. Happy shopping! This Acti9 product is a cuttable horizontal comb busbar 57 modules with 9mm auxiliary for Acti9 iC60 or Acti9 iK60. It is dedicated to Aux+3L installations. The type is AuxL1L2L3 (Auxiliary, Line). It is a set of 1 device. It is suitable for 22 devices (3P) with associated auxiliaries. The length is 1000mm.The total number of modules of 18mm is 57. The pin cross section is 16mm2. The type of electric connection is PIN. The number of phase is 1. The number of poles is 2. The Ie rated operational current at 40°C is 100A. The Isc short circuit current is compatible with the breaking capacity of Schneider Electric circuit breakers. The Ui rated insulation voltage is 500VAC. The Ue rated operational voltage is 415VAC. The color of the device is white RAL9003. The pollution degree is 3. According to IEC 60695-2-1 standard the fire resistance is self-extinguishing at 960°C within 30s. It complies with IEC 60947-7-1 and IEC 61439-2 standards. Specification
