COMBINATION ARRESTER V50 1P + NPE 280V

Download the 5093522 Combination Arrester V50 1-Pole + NPE 280 V product datasheet, click here!

Download the Surge Arrester product datasheet, click here!

Surge Arrester OBO

Surge Arrester or Combination Arrester is a tool that can protect electrical equipment from voltage or electric current drivers caused by external forces (such as lightning) or internal forces. Generally, this tool is installed at the entry point of the electrical system, which aims to protect the entire electrical system from potential electrical damage caused by sudden surges of electric current.

Surge Arrester Function:

• Chanelling high currents or excessive electrical energy to the ground
• Limiting voltage on electrical equipment
• Protecting electrical equipment from damage due to excessive voltage

Technical Characteristics:

• Product Code : 5093522
• Brand : OBO
• Product Name : COMBINATION ARRESTER V50 1P + NPE 280V
• Description : SURGE ARRESTER OBO - 5093522
• Weight : 0.32 kg
• Number of poles : 2
• Pole version : 1+N/PE
• Protection rating : IP20
• Maximum continuous voltage AC : 280
• Housing material surge protection components : PA UL 94 V-0
• For lightning current equipotential bonding to VDE 0185-305 (IEC 62305)
• Lightning current arresting capacity 12.5 kA (10/350) per pole, and up to 50 kA (10/350) in total
• Application for SURGE ARRESTER OBO 5093522: Lightning current equipotential bonding for building of class III and IV
