CONTACTOR 3P 75kW 160A AC-3 380/400V COIL 220VAC 1NO+1NC
| Pilih Arus pengenal |
|
||||||||||||||||||||||||||||||||
| Pilih Kontak bantu |
|
||||||||||||||||||||||||||||||||
| Kode Produk | LC1E160M5 | ||||||||||||||||||||||||||||||||
| Nama Produk | CONTACTOR 3P 75kW 160A AC-3 380/400V COIL 220VAC 1NO+1NC | ||||||||||||||||||||||||||||||||
| Keterangan | TVS SCHNEIDER ELECTRIC - LC1E160M5 | ||||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||||
| Rated Current | 160A | ||||||||||||||||||||||||||||||||
| Pole Contact Composition | 1NO+1NC | ||||||||||||||||||||||||||||||||
| Control Circuit Voltage | 220VAC | ||||||||||||||||||||||||||||||||
| Tipe | EasyPact TVS | ||||||||||||||||||||||||||||||||
|
Kode Produk : LC1E160M5
Brand : Schneider Electric
Nama Produk : CONTACTOR 3P 75kW 160A AC-3 380/400V COIL 220VAC 1NO+1NC
Keterangan : TVS SCHNEIDER ELECTRIC - LC1E160M5
Easy TeSys Control contactor 3 poles for motor applications up to 160A 80kW@440V. It provides a 220V 50Hz AC coil, 3NO built-in auxiliary contacts, power and control connections by screw clamp terminals. 120mm width for standard operating rates up to 1200 cycles per hour. It procures standard reliability and durability with 0.8 Mcycles electrical durability AC-3 and 4 Mcycles mechanical durability. It can cover -5°C to 55°C working temperature and mounted by DIN-rail, No derating up to 3000m altitude. Multi-standards certified (IEC, CCC, EAC) and Green Premium compliant (RoHs/Reach). Specification
