CONTACTOR 4P (2NO+2NC) 32A AC-1 COIL 220VAC 2 3
CONTACTOR 4P (2NO+2NC) 32A AC-1 COIL 220VAC
2
3

CONTACTOR 4P (2NO+2NC) 32A AC-1 COIL 220VAC

Pilih Arus pengenal
Pilih Tegangan coil
Kode Produk LC1D188M7
Nama Produk CONTACTOR 4P (2NO+2NC) 32A AC-1 COIL 220VAC
Keterangan TESYS D SCHNEIDER ELECTRIC - LC1D188M7
Brand Schneider Electric
Rated Current 32A
Pole Contact Composition 2NO+2NC
Control Circuit Voltage 220VAC
Tipe TeSys D

For a video explaining the product, click here!

TeSys Deca contactor, 4 poles (2NO+2NC), for non-inductive load applications up to 32A/690V AC-1. It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Specification
Type of electrical connection of main circuit Screw connection
Width 45 Millimetre
Rated control supply voltage AC 50 Hz 220 Volt
Rated control supply voltage AC 60 Hz 220 Volt
Number of normally closed contacts as main contact 2
Number of normally open contacts as main contact 2
Number of auxiliary contacts as normally closed contact 1
Number of auxiliary contacts as normally open contact 1
Modular version FALSE
Operating voltage AC 50 Hz 440 Volt
Depth 99 Millimetre
Operating voltage AC 60 Hz 440 Volt
Rated operation current Ie at AC-1, 400 V 32 Ampere
Height 91 Millimetre
Voltage type for actuating AC
Documents
Image of product
Image of product
Image of product
Image of product

Chat untuk Stock

Rp.807.858,-

40% Rp.1.346.430,-

Add to Cart
