CONTACTOR 4P (4NO) 20A AC-1 COIL 24VDC 2 3
CONTACTOR 4P (4NO) 20A AC-1 COIL 24VDC
2
3

CONTACTOR 4P (4NO) 20A AC-1 COIL 24VDC

Pilih Arus pengenal
Pilih Tegangan coil
Kode Produk LC1DT20BD
Nama Produk CONTACTOR 4P (4NO) 20A AC-1 COIL 24VDC
Keterangan TESYS D SCHNEIDER ELECTRIC - LC1DT20BD
Brand Schneider Electric
Rated Current 20A
Pole Contact Composition 4NO
Control Circuit Voltage 24VDC
Tipe TeSys D

For a video explaining the product, click here!

TeSys Deca contactor, 4 poles (4NO), for non-inductive load applications up to 20A/690V AC-1. It provides a 24V DC coil with transient suppressor module, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Specification
Type of electrical connection of main circuit Screw connection
Width 45 Millimetre
Number of normally closed contacts as main contact 0
Number of normally open contacts as main contact 4
Number of auxiliary contacts as normally closed contact 1
Number of auxiliary contacts as normally open contact 1
Modular version FALSE
Depth 99 Millimetre
Rated operation current Ie at AC-1, 400 V 20 Ampere
Rated control supply voltage DC 24 Volt
Height 85 Millimetre
Voltage type for actuating DC
Documents
Image of product
Image of product
Image of product
Image of product

Chat untuk Stock

Rp.1.097.568,-

40% Rp.1.829.280,-

Add to Cart

Free Ongkir Jabodetabek Menggunakan Kurir Toko Listrikkita
