ETHERNET SWITCHBOARD DISPLAY FDM128 UP TO 8 CONNECTED DEVICES IP65
| Pilih Tipe |
|
||||||
| Pilih Nama produk |
|
||||||
| Kode Produk | LV434128 | ||||||
| Nama Produk | ETHERNET SWITCHBOARD DISPLAY FDM128 UP TO 8 CONNECTED DEVICES IP65 | ||||||
| Keterangan | SCREEN 115.2X86.4MM SCHNEIDER ELECTRIC - LV434128 | ||||||
| Brand | Schneider Electric | ||||||
| Type | PowerTag | ||||||
|
Kode Produk : LV434128 Brand : Schneider Electric Nama Produk : ETHERNET SWITCHBOARD DISPLAY FDM128 UP TO 8 CONNECTED DEVICES IP65 Keterangan : SCREEN 115.2X86.4MM SCHNEIDER ELECTRIC - LV434128 This FDM128 is an intelligent Ethernet switchboard display module and it is part of EnerlinX communication system. This display unit is compatible with Masterpact, Compact, PowerPact and PowerTag Link devices. It collects data from up to 8 devices over Ethernet, for a possibility of up to 160 PowerTag connected. FDM128 displays the measurements, alarms, and operating assistance data. It has a color TFT LCD touch screen, with a high resolution (320 pixels x 240 pixels). The FDM128 is equipped with a 24VDC terminal block and one RJ45 socket for Ethernet connection. It is easily installed in a switchboard through a standard 22mm door hole, and its dimensions are 129mm x 96mm x 56,5mm. The operating temperature range is between -10°C to 55°C, and the protection degree is IP65 on the front face. The FDM128 display module is entirely part of the EcoStruxure Power architecture and Ethernet ready smart panels. The FDM128 firmware can be updated using EcoStruxure Power Commission software. Specification
Documents
|
|||||||
