FLOODLIGHT 120W BVP432 LED161/CW 220-240V SWB GM 757 COOL WHITE

LED Floodlight is a lighting source designed to illuminate large areas with light that is evenly distributed, but with high intensity. The main characteristic of a floodlight is its ability to illuminate a large area with relatively even light and without creating many shadows.

The Philips SmartBright LED Floodlight is a multi-purpose flashlight designed to deliver significant energy savings, an ideal solution for a wide range of flashlight applications. This product is also designed to meet appropriate safety and performance standards, giving you reliability and long-lasting performance.

Philips SmartBright LED Floodlight feature :

• Various CCT options: 3000K/4000K/5700K
• Various power options: 30w/50w/70w/100w/150w/200w
• Long service life: 30,000 hours (L70B50)
• Wide working temperature range: -40°C ~ +45°C
• High system efficacy: up to 95lm/w

Philips SmartBright LED Floodlight can be used for architectural lighting, landscape lighting, billboard lighting, parking area lighting, decoration and security.

Benefits of using Philips SmartBright LED Floodlight

• Replacement of conventional HID lamps
• Easy to install
• Tremendous energy savings
• High reliability and quality

Specifications

General Information

• Driver included : Yes
• Lighting Technology : LED
• CE mark : CE mark

Light Technical

• Luminous Flux : 16,100 lm
• Correlated Color Temperature (Nom) : 5700 K
• Luminous Efficacy (rated) (Nom) : 134 lm/W
• Color rendering index (CRI) : >70
• Light source color : 757 cool white
• Optical cover type : Polycarbonate bowl/cover

Operating and Electrical

• Input Voltage : 220 to 240 V
• Line Frequency : 50 or 60 Hz
• Power Consumption : 120 W
• Power Factor (Fraction) : 0.9
• Connection : Flying leads/wires
• Cable : Cable 1.5 m without plug
• Number of products on MCB of 16 A type B : 18

Temperature

• Ambient temperature range : -40 to +50 °C

Controls and Dimming

• Dimmable : No
• Control interface : -

Mechanical and Housing

• Housing Material : Aluminum die cast
• Optical cover material : Polycarbonate
• Housing Color : Gray
• Overall length : 347 mm
• Overall width : 414 mm
• Overall height : 77 mm
• Dimensions (Height x Width x Depth) : 77 x 414 x 347 mm

Approval and Application

• Ingress protection code : IP66 [Dust penetration-protected, jet-proof]
• Mech. impact protection code : IK08 [5 J vandal-protected]
• Protection class IEC : Safety class I

Initial Performance (IEC Compliant)

• Luminous flux tolerance : +/-10%
• Power consumption tolerance : +/-10%
