GEARED MOTOR DEVICE 220...250V AC-DC E1.2

An air circuit breaker (ACB) is a type of electrical protection device commonly used in electrical systems. An air circuit breaker is an electrical protection device that is used to cut off the flow of electricity in an electrical circuit when there is a disturbance or excess current. This tool is generally used in industrial electrical panels and can be used in electrical systems with quite large voltages.

An air circuit breaker works by cutting off the flow of electricity in an electrical circuit when there is a disturbance or excess current. The Air Circuit Breaker uses a special system consisting of several components, such as a trip unit, operating mechanism, and current transformer. When a disturbance occurs in an electrical circuit, the trip unit will detect an excess current. Then, it gives a signal to the operating mechanism to cut off the electricity in the circuit. After the electricity supply is cut off, the air circuit breaker will extinguish the arc that occurs using the arc extinguishing system that has been prepared.

The main function of an air circuit breaker is to protect electrical equipment and systems from damage due to overcurrent, which usually occurs due to short circuits or overloads. The following are some of the functions of the air circuit breaker :

1. Protection from overcurrent

Overcurrent occurs when the current flowing exceeds the maximum capacity that can be tolerated by the system or equipment. This can happen for various reasons, such as a fault in the wiring or a sudden increase in electrical load. The air circuit breaker will cut off electricity when it detects this condition, protecting equipment from damage.

2. Protection from short circuit

A short circuit is a condition in which electric current flows through a path that has low resistance, usually due to electric wires meeting directly without any resistance. This can cause very high current increases, which can damage equipment and even cause a fire. The air circuit breaker detects and cuts off electricity in this condition.

3. Manual disconnect

The air circuit breaker also allows manual circuit breaking. This is especially useful in situations where maintenance or repairs need to be carried out on the electrical system, allowing the circuit to be broken and eliminating the risk of electric shock.

4. Fault clearing

In the case of a disturbance or 'fault' in the system, the air circuit breaker not only cuts off the electricity but also helps in the 'fault clearing' process. This means they help isolate problematic parts of the system.

So, the main purpose of an air circuit breaker is to ensure the safety of the electrical system and equipment connected to it, as well as prevent potentially dangerous situations such as fires due to short circuits or excessive current.

ABB ACB can be used at low voltage and medium voltage. Air at atmospheric pressure is used as a damper for arcs that arise due to switching processes or disturbances.

ACB ABB SACE Emax 2 sets a new circuit breaker benchmark for current and future needs, matching all the requirements of new power networks thanks to its distinctive features, including :

• PerformanceFour sizes are available, ensuring high performance in compact dimensions. Triple-marking certification (IEC, UL, CCC). Certified for Class 1 active energy measurements according to the IEC 61557-12 standard.
• ControlsAll-in-One innovation is able to manage all electrical network conditions thanks to advanced functions such as load shedding, power controller, ATS, interface protection, synchrocheck logic, and adaptive protection.
• ConnectivitySeamless integration into all automation and energy management systems thanks to eight supported communication protocols. Easy connection to the ABB AbilityTM Electrical Distribution Control System cloud computing platform. Long-distance connection via embedded Bluetooth Low Energy technology.
• Ease of useEasy and safe operation and maintenance. Plug-and-play accessories. User-friendly commissioning tool. The platform can evolve over the lifecycle through ABB's MarketplaceTM capabilities.
