MCCB/NFB 3P 250A 36KA/415VAC
| Kode Produk | EZCV250H3250 | ||||||||||||||||||||||||||||||||||||||||||||
| Nama Produk | MCCB/NFB 3P 250A 36KA/415VAC | ||||||||||||||||||||||||||||||||||||||||||||
| Keterangan | EZCV250H SCHNEIDER ELECTRIC - EZCV250H3250 | ||||||||||||||||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||||||||||||||||
| Poles | 3P | ||||||||||||||||||||||||||||||||||||||||||||
| Rated Current | 250A | ||||||||||||||||||||||||||||||||||||||||||||
| Breaking Capacity | 36kA | ||||||||||||||||||||||||||||||||||||||||||||
| Tipe | EasyPact EZC | ||||||||||||||||||||||||||||||||||||||||||||
|
To download the product datasheet EZCV250H3250 MCCB/NFB 3P 250A 36KA/415VAC, please click here! Technical Characteristic:
Schneider Electric EasyPact EZC It is a direct black rotary handle for EasyPact EZC 100 devices. It is suitable for isolation and it is used for standard switchboards. There is an indication of the 3 Compact NSX positions O (OFF), I (ON) and tripped. It maintains circuit breaker locking capability by 1 to 3 padlocks (not supplied). The degrees of protection are IP40 and IK07. You can shop safely at ListrikKita.com because all the goods we sell are guaranteed to be 100% genuine, have an official guarantee, and can be accompanied by a letter of authenticity. To get the best prices and further information, please contact our sales or marketing team by clicking here. Happy shopping. This is a 250A circuit breaker for EasyPact EZC250H. This product can work below rated operational voltage(Ue) 440VAC at 50/60Hz. The ultimate breaking capacity(Icu) is 36kA at 440V, in terms of complete range Ics= 50%Icu. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 105mm(width),165mm(height),68mm(Depth). Specification
