TESYS D CONTROL RELAY 3NO+2NC 690V 24VDC STANDARD COIL

Untuk unduh datasheet produk CAD32BD TESYS D CONTROL RELAY 3NO+2NC 690V 24VDC STANDARD COIL SCHNEIDER ELECTRIC, silahkan klik di sini!

Karakteristik Teknikal:

• Kode Produk: CAD32BD
• Merek: Schneider Electric
• Nama Produk: TESYS D CONTROL RELAY 3NO+2NC 690V 24VDC STANDARD COIL
• Deskripsi: RELAY CONTROL TESYS D KONTROL DC SCHNEIDER ELECTRIC - CAD32BD
• Rentang:
  TeSys
  TeSys Deca
• Nama produk: TeSys CAD
  Jenis produk atau komponen: Relai kontrol
• Nama singkat perangkat: CAD
  Aplikasi kontaktor: Sirkuit kontrol
• Kategori penggunaan:
  DC-13
  AC-15
  AC-14
• Komposisi kontak kutub: 3 NO + 2 NC
• [Ue] tegangan operasi terukur: <= 690 V AC 25...400 Hz
• Jenis sirkuit kontrol: Standar DC
• [Uc] tegangan sirkuit kontrol: 24 V DC
• [Uimp] tegangan tahan impuls terukur: 6 kV sesuai dengan IEC 60947
• [Ith] arus termal udara bebas konvensional: 10 A (pada 60 °C)
• Daya tahan mekanis: 30 Mcycles
• Kecepatan operasi maksimum: 180 cyc/mn
• Konstanta waktu: 28 ms
• Daya lonjakan dalam W: 5,4 W (pada 20 °C)
• Konsumsi daya hold-in dalam W: 5,4 W pada 20 °C
• Tegangan switching minimum: 17 V
• Arus switching minimum: 5 mA
• Tinggi: 77 mm
• Lebar: 45 mm
• Kedalaman: 93 mm
• Berat produk: 0,58 kg

TeSys Control Relays Schneider Electric

TeSys adalah solusi manajemen dan kontrol motor inovatif dari pemimpin pasar global. TeSys menawarkan produk dan solusi yang terhubung dan efisien untuk sistem pengalihan dan proteksi motor dan beban yang mematuhi semua standar kelistrikan global utama.
Relai Kontrol TeSys D, K, dan SK merupakan rangkaian yang mencakup relai, relai kontrol mini, blok kontak bantu, modul penekan koil, dan aksesori.

Anda dapat berbelanja dengan aman di ListrikKita.com karena semua barang yang kami jual dijamin 100% asli, bergaransi resmi, dan dapat disertai dengan surat keaslian barang. Untuk informasi lebih lanjut atau ingin melakukan pembelian dalam jumlah besar bisa menghubungi tim sales atau marketing kami, dengan klik di sini. Selamat berbelanja!

TeSys D control relay, 5 contacts (3NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 24V DC control circuit with no inrush consumption and equipped with a surge suppression device, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -40/+60°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium product (RoHS/REACh).

Specification

Suitable for manual operation	FALSE
Width	45 Millimetre
Rated switch current	0.005 Ampere
Interface	FALSE
Number of auxiliary contacts as normally closed contact	2
Connection type auxiliary circuit	Screw connection
Number of auxiliary contacts as normally open contact	3
With LED indication	FALSE
Number of auxiliary contacts as change-over contact	0
Mounting method	DIN-rail/screw
Rated operation current Ie, 400 V	10 Ampere
Rated operation current	10 Ampere
Depth	84 Millimetre
Operating voltage DC	690 Volt
Voltage type (operating voltage)	DC
Rated control supply voltage DC	24 Volt
Height	77 Millimetre
Voltage type for actuating	DC
Number of auxiliary contacts as normally closed contact, delayed switching	0
Number of auxiliary contacts as normally open contact, leading	0

Documents

• Circularity Profile - TeSys Deca 3-pole contactor 09A DC
• CAD - CAD32BD_CAD_DOC
• CAD -
• CAD -
• CAD -
• CAD -
• Environmental Disclosure - TeSys Deca 3-pole contactor 09A DC
• Instruction sheet - LC1D 9 to 38 A AC/DC contactors with screw clamp terminals - Instruction Sheet
• Catalog - TeSys - Catalog 2025 - Innovative and connected solutions for motor starters
