SURGE ARRESTER 1P+N 8KA 350V
| Pilih Jumlah kutub |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pilih I maks (ka) |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Kode Produk | A9L08501 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nama Produk | SURGE ARRESTER 1P+N 8KA 350V | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Keterangan | IPRD 8R WITH REMOTE TRANSF SCHNEIDER ELECTRIC - A9L08501 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Jumlah Kutub | 1P+N | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Kapasitas Pemutusan | 8kA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tipe | Surge Arrester | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Untuk unduh datasheet produk A9L08501 iPRD8r Modular Surge Arrester 1P + N 350V with Remote Transfert, silakan klik di sini! Surge Arrester Schneider Electric Surge Arrester merupakan alat yang dapat melindungi peralatan listrik dari lonjakan tegangan atau arus listrik yang disebabkan oleh gaya eksternal (seperti petir) maupun gaya internal. Umumnya, alat ini dipasang pada titik masuk sistem kelistrikan, dengan tujuan untuk melindungi keseluruhan sistem kelistrikan dari potensi kerusakan listrik yang disebabkan oleh arus listrik yang melonjak tiba-tiba. Fungsi Surge Arrester:
Karakteristik Teknikal:
Anda dapat berbelanja dengan aman di ListrikKita.com karena semua barang yang kami jual dijamin 100% asli, bergaransi resmi, dan dapat disertai dengan surat keaslian barang. Untuk informasi lebih lanjut atau ingin melakukan pembelian dalam jumlah besar bisa menghubungi tim sales atau marketing kami, dengan klik di sini. Selamat berbelanja! This Acti9 iPRD8r surge arrester protects 1P+N installations. It allows quick replacement of damaged cartridges. The Imax maximum discharge current is 8kA .The In nominal discharge current is 2.5kA. The iPRD8r ensures secondary protection of loads to be protected and is placed in cascade with the incoming surge arresters. This surge arrester is required when the loads to be protected are at a distance of more than 10 m from the incoming surge arrester. The surge arresters with "r" indication have remote transfer of the information "Cartridge to be replaced". The Uc maximum continuous operating voltage in common mode is 260VAC between neutral and earth, and is 350VAC between phase and earth. The Uc maximum continuous operating voltage in differential mode (between phase and neutral) is 350VAC. The Up Voltage protection level in common mode is 1.4kV between neutral and earth in type 2, and 1.1kV between neutral and earth in type 3. The Up Voltage protection level in differential mode (between phase and neutral) is 1kV in type 2, and 1.1kV in type 3. The Ue rated operational voltage is 230VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 36mm x (H) 85mm x (D) 69mm. The weight is 215g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards. Specification
