SWITCH DISCONNECTORS 3P 100A

To download the product datasheet LV429629 SWITCH DISCONNECTORS 3P 100A, please click here!

Technical Characteristic:

• Product Code : LV429629
• Brand : Schneider Electric
• Product Name : SWITCH DISCONNECTORS 3P 100A
• Description : COMPACT NSX-NA, NS-NA SCHNEIDER ELECTRIC - LV429629
• Range : ComPact
• Product name : ComPact NSX
• Product or component type : Switch disconnector
• Device short name : Compact NSX100NA
• Poles description : 3P
• [Ui] rated insulation voltage : 800 V AC 50/60 Hz conforming to IEC 60947-3
• [Uimp] rated impulse withstand voltage : 8 kV conforming to IEC 60947-3
• [Ith] conventional free air thermal current : 100 A at 60 °C
• Control type : Toggle
• Mounting mode : Fixed
• Mounting support : Backplate
• Connection pitch : 35 mm
• Height : 161 mm
• Width : 105 mm
• Depth : 86 mm
• Net weight : 1.8 kg
• Warranty : 12 months

Schneider Electric ComPacT NSX NA

ComPact NSX NA switch disconnectors are designed to provide reliable isolation switching. The solution has the same footprint as ComPact NSX circuit breakers and comes with compatible accessories up to 630 A. The ComPact NSX NA switch disconnector range can be adapted to fit many low voltage (LV) applications where isolation is required. The range comes in two frame sizes with a variety of accessories compatible with ComPact NSX circuit breakers, including for motor control and source-changeovers (TransferPact).

Specifications :

• Nominal current: 100 to 630 A up to 690 V
• 2, 3 and 4 pole versions available
• Wealth of auxiliaries and accessories (field installable)
• Available in fixed, withdrawable (plug-in and chassis) versions
• Same installation as the ComPact NSX circuit breaker; same size, power connections and fixation

You can shop safely at ListrikKita.com because all the goods we sell are guaranteed to be 100% genuine, have an official guarantee, and can be accompanied by a letter of authenticity. To get the best prices and further information, please contact our sales or marketing team by clicking here. Happy shopping.

This Compact NSX100NA is a complete 3 poles switch disconnector. It is used to control and isolate electrical distribution circuits and it requires an upstream protection. The operational current is 100A at 415VAC 50/60Hz for AC22A and AC23A utilization categories. The operational voltage is 690VAC 50/60Hz. It comes with a variety of optional functions and accessories common with Compact NSX circuit breakers. The dimensions for this 3 poles version are 105mm x 161mm x 86mm. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Specification

Type of electrical connection of main circuit	Screw connection
Version as emergency stop installation	FALSE
Type of control element	Toggle
Version as reversing switch	FALSE
Suitable for front mounting centre	FALSE
Rated permanent current Iu	100 Ampere
Max. rated operation voltage Ue AC	690 Volt
Number of poles	3
Version as main switch	TRUE
Rated short-time withstand current lcw	1.8 kiloampere
Voltage release optional	TRUE
Device construction	Built-in device fixed built-in technique
Interlockable	TRUE
Version as maintenance-/service switch	TRUE
Number of auxiliary contacts as normally closed contact	0
Version as safety switch	FALSE
Number of auxiliary contacts as change-over contact	5
Number of auxiliary contacts as normally open contact	0
Degree of protection (IP), front side	IP30
Rated operating voltage	690 Volt
Colour control element	Black
Suitable for front mounting 4-hole	TRUE
Number of switches	1
Rated permanent current at AC-21, 400 V	100 Ampere
Motor drive integrated	FALSE
Suitable for distribution board installation	TRUE
Suitable for intermediate mounting	FALSE
Suitable for floor mounting	TRUE
Motor drive optional	TRUE
Rated permanent current at AC-23, 400 V	100 Ampere

Documents

• Instruction sheet - ComPact NSX100-250A / FPower NSX / GV7 - Circuit breaker/Switch-disconnector - Instruction Sheet
• User guide - ComPact NSX100-630 - User Guide
• Catalog - Catalogue Compact NSX & NSXm circuit breakers and switch disconnectors from 16 to 630A up to 690V
