VOLTAGE RELEASE MX 200-250V DC/AC 50/60HZ

Name: VOLTAGE RELEASE MX 200-250V DC/AC 50/60HZ
Brand: SCHNEIDER ELECTRIC
Price: 1817459.00 IDR
Availability: InStock

Kode Produk

33813

Nama Produk

Keterangan

ACCESSORIES COMPACT NS SCHNEIDER ELECTRIC - 33813

Brand

Schneider Electric

Tipe

Compact NS

Kode Produk : 33813 Brand : Schneider Electric Nama Produk : VOLTAGE RELEASE MX 200-250V DC/AC 50/60 HZ Keterangan : ACCESSORIES COMPACT NS SCHNEIDER ELECTRIC - 33813

This is a MX shunt trip release for drawout Compact NS 630b to Compact NS 1600 devices. Its rated voltage is 200VDC to 250VDC or 200VAC to 250VAC 50/60Hz. It is an auxiliary used for emergency off or remote opening applications. This auxiliary opens the circuit breaker when the control voltage Un rises above 70% of its rated voltage Un. It complies with IEC 60947-2 standard. Compact NS 630b to Compact NS 1600 device can be equipped with 1 MX or 1 MN auxiliary.

Specification

Rated control supply voltage AC 50 Hz	200…250 Volt
Rated control supply voltage AC 60 Hz	200…250 Volt
Suitable for motor safety switch	FALSE
Type of electric connection	Flat plug-in connection
Suitable for power circuit breaker	TRUE
Suitable for off-load switch	TRUE
Power consumption	4.5 Watt
Suitable for overload relay	FALSE
Number of contacts as normally open contact	0
Number of contacts as change-over contact	0
Voltage type for actuating	AC/DC
Rated control supply voltage DC	200…250 Volt
Number of contacts as normally closed contact	0
